1000Gsm PVC Laminated Tarpaulin – LPT1040/1000
1000Gsm PVC Laminated Tarpaulin – LPT1040/1000
This high-performance vinyl tarp features a 1000D 20×20 polyester base with 1000 GSM density, delivering exceptional durability for industrial and emergency use. With B1 fire resistance, UV protection, and superior tear strength (409/351N), it withstands harsh conditions while maintaining visibility. Ideal for construction covers, emergency shelters, and equipment protection, its 0.8mm thickness and 93N/cm peel strength ensure long-term reliability. The bright white surface enhances reflectivity for safety in low-light environments. Trust this rugged tarp for demanding projects where strength and compliance matter.
Fire Retardant
Weldable
Tear Resistant
Anti-UV
Weather Ability
Longlife Time
LonaTarp® 0.8mm PVC Tarpaulin Product Specifications
| Fabric Properties | Parameters | Testing Method |
| ■ Technical properties | ||
| Total Weight | 1000 Gsm/m² 29.5 OZ/YD² | DIN53352/ BS3424 |
| Base Fabric | 100%PES 1000D 20X20/inch | DIN EN ISO2060/ DIN53853 |
| Tensile Strength (warp/weft) | 2167/2443 N/5cm | ISO1421 |
| Tear Strength (warp/weft) | 409/351 N/5cm | DIN 53363 |
| Adhesion | 93 N/5cm | DIN 53357 |
| Temperature Resistance | -30℃ / +70℃ | DIN53372 |
| Number of Flexes | >50,000 | DIN53359A |
| Flammability(Optional) | DIN4102:B1, NFPA701, M2 | |
| Max Width | 3.2M (10.50Feet) | |
| Application | Industry, Safety & Protection | |
| All technical data set out above are for product information purposes only and not legally binding, and will cease to apply with any further development of the products. The most recent technical data will be provided by LonaTarp® on request. Please note that the technical data as set out above are average values only. All values are generated through tests by established laboratories in accordance with industry standards. Results may vary if testing is executed by different laboratories or due to different standard interpretation. All technical data apply to new products only. Deviations may occur due to production procedures. | ||
Try LonaTarp® Customize Your Terpal PVC Now
- PVC Formulation Properties
- Strength, Weight and Thickness
- Glossy, Matte, Color, Print and 3D Embossed Patterns
- Tarpaulin Roll Sizes and Packaging
- Cutting, Heat Sealing, Sewing, Add Eyelets, and Accessories Purchasing
